| Name |
MSS SPRAY NOZZLE |
Spray angel |
120вк ~ 140вк |
| Type |
Centrifugal type MSS 15A |
Port diameter |
15A |
| Use |
Removing foams generated in waste
water, sewage, night soil treatment
facilities and for other uses |
Material |
ABS resin |
Installation
space
|
500mm or more up from the water surface |
| Flow rate |
8зд/min (8~10зд/min option available) |
Weight |
30g |
| Supply pressure |
Max. 1~1.5kg/cm3 |
Installation
direction
|
140вк direction |
| Pump head |
20m |
Interval |
1000mm ~ 1200mm |
|
|
Feature
- High concentration microorganism oxidation(MLSS 6000 P.P.M) available.
- Best features include high concentration soluble oxygen percentage and dynamic agitation.
- No cleaning neede through 1-time installation.
- Low price. |
|
| |
|
